    Soybean And Meal Bran Fully Automatic Powder Packing Machine 50kg 1240mm

    Ask Lasest Price
    Brand Name : EWINALL
    Model Number : QZB-500B
    Certification : CE,QMS,ISO,CCPIT
    Payment Terms : L/C, T/T
    Supply Ability : 5 days per set
    Delivery Time : 40 days
    • Product Details
    • Company Profile

    Soybean And Meal Bran Fully Automatic Powder Packing Machine 50kg 1240mm

    Large-Package Soybean Meal Bran Fully Automatic Packaging Machine

    QZB-500B fully automatic packing machine


    The main technical performance of the packaging unit


    1. The main basis of the design: automatic packaging, improve efficiency, save manpower, and convenient operation.

    2.Product technical parameters, packaging materials and equipment operating conditions

    (1) Packing material name: bran or other powder and granular material

    — Packaging temperature: material temperature is less than 50℃

    — Liquidity: General

    (2) Stand-alone packaging system capabilities:

    Weighing range:25-50kg/bag

    Weighing error:±2‰;The weighing unit of the packaging machine is an optional product.

    Capacity:8-10 bags/minute;

    (3) Packaging bag requirements:

    Type: Open type

    Packing material: non-coated woven bag, without film woven bag, the bag is required to be flat, no corners, bending phenomenon, no folding and wrinkling are allowed, the bag mouth is a woven bag that has been rubbed through the bag mouth through the process of rubbing the mouth .

    Size:Length:1100-1240 mm

    Width:660-720 mm

    weight:100-124 g

    Warp and weft density, root /10cm:>40×40

    Radial pull(N/50mm):50/70kg>440/490

    Zonal pull up(N/50mm):50/70kg>420/470

    (4) Equipment operating conditions

    Ambient temperature: 0~40°

    Humidity: maximum 90%

    Consumption:83L/min(0.5MPa)

    Power:6kw


    THE FACTORY
