Intelligent Pad Control Machine Applied To Grain,Beans And Rice
Factory
DCS-50FB-C rice and grain packing with touch screen,PLC,controller
and six load cells
The main components
| Name | Brand | Note |
| Weighing controller | GM | Reserved RS232/485 serial port, standard Modbus RTU communication
protocol, data communication with peripheral management system.
Optional mini printer. |
| PLC | DELTA |
| Load cell | METLLER TOLEDO (USA)/HBM(GERMANY) |
| Solenoid valve | Mindman |
| Sensor | SICK(Germany) |
| Proximity switch | OMRON(JAPAN) |
| Air comtrol | AIRTAC |
| Cylinder | AIRTAC
|
Applicant
It is suitable for automatic quantitative packaging of materials
with good fluidity (such as: rice, white sugar, feed, plastic
pellets, etc.).
Features:
1. Weighing instrument + PLC dual-core control technology, A/D
conversion times reach 200 times per second. It ensures the strict
requirements for the weighing speed and weighing accuracy of the
equipment.
2. It adopts three-sensor structure, balanced layout of weighing
cylinder, reasonable force, which improves the service life of the
equipment, and is not interfered by machine vibration in the
workshop, and has higher stability and anti-interference ability.
3. Friendly man-machine interface, simple and convenient equipment
operation, reducing labor intensity, improving the level of
intelligence in workshop operation, intelligent storage of
production reports, and data communication functions.
4. Safety and sanitation. In order to ensure food safety, we use
stainless steel for the feeding, weighing barrels and other
material contact parts, and the interior is polished smoothly to
prevent dead corners and no food residues to prevent the residual
rice from becoming mildewed and rancidity affecting the rice
quality.
5. To prevent rodent damage and acid corrosion, we have adopted a
closed working room. All lines, sensors, and solenoid valves are
equipped with steel wire grooves or protective iron boxes, which
completely isolates the corrosion and wear of rice flour and water
vapor to the cylinder and sensors. , Extending the trouble-free
operation time of the equipment.
6. Handle mechanism of external adjustment mechanism. Using a
scaled handle adjustment device, the size of the "feeding port" can
be adjusted to the best working mode for different water content
and different grains of rice to ensure the weighing effect.
7. The cylinder works frequently and has high strength. The
double-cylinder discharge mechanism developed by us solves many
problems such as the high frequency of cylinder use, which causes
the cylinder with solenoid valve and other original components to
have short life, many failures, and unstable performance.
8. Digital intelligent automatic lifting conveyor, the conveyor can
quickly switch to the appropriate position according to different
packaging, and the lifting height of different varieties can be
memorized.
9. Light and easy to turn, rotating column, multi-functional
packaging method, for different packaging, different sealing forms,
designed sewing machine and heat sealing machine that can be
switched by rotation, allowing users to feel a convenient and
easy-to-use experience.
10. Intelligent multi-point oil supply spray lubrication system of
the sewing machine. We arrange the oil injection pipeline
reasonably at more than a dozen key points of the sewing machine.
The oil mist particles are injected regularly and quantitatively
through the program calculation to ensure the lubrication of each
key moving part. , You don’t have to worry about forgetting to
refuel the sewing machine. (Optional)
11. Firmly lock in freshness. It has the function of fresh-keeping
gas input to meet the individual needs of customers for rice
packaging. (Optional)
Parameter
| Specification | DCS-50FB1 |
| Weighing range (kg) | 5-50 |
| capacity(bag/h) | 600-1000 |
| Division(g) | 2 |
| Accurancy | X(0.2) |
| Power | 4N-AC380V 50Hz 1.1 KW |
| Air | 0.4-0.5MPa 16.7L/min |
Dimension(mm) L*W*H | 3120*960*2692 |
