    0.6MPa Three Phase Robotic Bag Palletizer vacuum Big Bag Food Automatic Packing Line

    Ask Lasest Price
    Brand Name : EWINALL
    Model Number : ZDJ-1800
    Certification : ISO,CE,QMS,CCPIT
    Payment Terms : L/C, T/T
    Supply Ability : 1 set 1 day
    Delivery Time : 40 days
    • Product Details
    • Company Profile

    0.6MPa Three Phase Robotic Bag Palletizer vacuum Big Bag Food Automatic Packing Line

    Automatic Small Bag In Big Bag Style Bagging Machine

    High speed bagging machine with servo motor and PLC control


    The package information:


    ModelZDJ-1800
    StyleFlow down
    Package rangea.5kg×10b.5kg×5c.10kg×5
    The size of packagelength(mm)970~1000700~750850~880
    width(mm)600600700

    ZDJ-1800 Main technology information


    packing capacity:

    The weightspeed
    5kg×10≤1800bags/h
    5kg×5≤1500 bags/h
    10kg×5≤1500 bags/h

    Air pressure:(0.5~0.6)MPa

    Consumption:1 m3/h

    Power:AC380V±10%,50Hz,three phase five wire,

    rated power:5kW

    Envirment temperature:0~40℃

    environment humidity:Not more than 90% RH at 40 ° C, allowing greater humidity at low temperatures

    Grounding form:TN-S
